EnviroLight SX 200W LED Solar Street Light

Availability :

This is Non-Stocking item. We will contact you with current lead time within one-two business days once Order is placed. Our Team of Experts will help to process your order further.

Product Description :

Our integrated solar street light which integrates highly efficient solar panels, LED lamp, and the Li-Fe battery into a single product, along with a human intelligence induction system, this product is ideal for anyone looking for a low-energy, long-lasting, high-luminance, and free maintenance lighting solution. At the same time, it’s convenient to ship and install.

The Integrated Solar Street Light is perfect for almost any solar lighting application.  This includes lighting a garden, residential area, courtyard, parking area or provide the light in roads where it’s necessary. The battery provides the power for the light fixtures, and the solar panel provides the charge for the battery.

The product is made up with the integrated parts (solar panel, Li-Fe battery, LED, MPPT controller and human intelligence induction system) and the light pole (pole not included). The solar panel converts sunlight into electricity which is then stored in the Li-Fe battery via controller, the LED light will work in night automatically by light sensor control, and provide light for the dark area, while the human intelligence induction system can save the energy when the lighting is not necessary.

Housing

Die cast aluminum housing.
Meets 3G vibration per C136.31-2010.

LED & Optical Assembly

Structured LED array for optimized roadway photometric distribution.
Evolve light engine consisting of scalable reflective technology designed to optimize application efficiency and minimize glare.
Reverse facing light engine options available.
Utilizes high brightness LEDs, 70 CRI at 4000K typical.
LM-79 tests and reports are performed in accordance with IESNA standards.

Ratings

IP66 rated optical enclosure per ANSI C136.25-2009.
Temperature ratings:
40°C to 50°C for 525mA and 700mA skus except for ERS4 @ 347-480V (-40°C to +45°C)
40°C to +40°C for 1050mA skus
Upward Light Output Ratio (ULOR) = 0.

Mounting

Slipfitter with +/- 5 degree of adjustment for leveling.
Integral die cast mounting pipe stop feature.
Wildlife intrusion protection at mounting pipe entry.
Adjustable for 1.25 in. or 2 in. mounting pipe.
Trunnion
Knuckle Slipfitter for O.D. Tenon
Knuckle Slipfitter for O.D. Pipe
Knuckle Wall Mount
Finish

Corrosion resistant polyester powder painted, minimum 2.0 mil. thickness.
Standard colors: Black and Gray.
RAL & custom colors available.
Electrical

12V DC; internal storage & charging circuit
System power factor is >90% and THD <20%.*
Class “A” audible sound rating
Light Source: 2750 Lumen LED Cree
Solar Panel: 50 Watts PMaxx
Battery: LiIon: 21Ahr
Lighting RunTime: 12hr (at full power); power saving model 24hr.

$1,599.95

SKU: EnviroLight-SX-200W Categories: ,

Description

Availability :

This is Non-Stocking item. We will contact you with current lead time within one-two business days once Order is placed. Our Team of Experts will help to process your order further.

Product Description :

Our integrated solar street light which integrates highly efficient solar panels, LED lamp, and the Li-Fe battery into a single product, along with a human intelligence induction system, this product is ideal for anyone looking for a low-energy, long-lasting, high-luminance, and free maintenance lighting solution. At the same time, it’s convenient to ship and install.

The Integrated Solar Street Light is perfect for almost any solar lighting application.  This includes lighting a garden, residential area, courtyard, parking area or provide the light in roads where it’s necessary. The battery provides the power for the light fixtures, and the solar panel provides the charge for the battery.

The product is made up with the integrated parts (solar panel, Li-Fe battery, LED, MPPT controller and human intelligence induction system) and the light pole (pole not included). The solar panel converts sunlight into electricity which is then stored in the Li-Fe battery via controller, the LED light will work in night automatically by light sensor control, and provide light for the dark area, while the human intelligence induction system can save the energy when the lighting is not necessary.

Housing

Die cast aluminum housing.
Meets 3G vibration per C136.31-2010.

LED & Optical Assembly

Structured LED array for optimized roadway photometric distribution.
Evolve light engine consisting of scalable reflective technology designed to optimize application efficiency and minimize glare.
Reverse facing light engine options available.
Utilizes high brightness LEDs, 70 CRI at 4000K typical.
LM-79 tests and reports are performed in accordance with IESNA standards.

Ratings

IP66 rated optical enclosure per ANSI C136.25-2009.
Temperature ratings:
40°C to 50°C for 525mA and 700mA skus except for ERS4 @ 347-480V (-40°C to +45°C)
40°C to +40°C for 1050mA skus
Upward Light Output Ratio (ULOR) = 0.

Mounting

Slipfitter with +/- 5 degree of adjustment for leveling.
Integral die cast mounting pipe stop feature.
Wildlife intrusion protection at mounting pipe entry.
Adjustable for 1.25 in. or 2 in. mounting pipe.
Trunnion
Knuckle Slipfitter for O.D. Tenon
Knuckle Slipfitter for O.D. Pipe
Knuckle Wall Mount
Finish

Corrosion resistant polyester powder painted, minimum 2.0 mil. thickness.
Standard colors: Black and Gray.
RAL & custom colors available.
Electrical

12V DC; internal storage & charging circuit
System power factor is >90% and THD <20%.*
Class “A” audible sound rating
Light Source: 2750 Lumen LED Cree
Solar Panel: 50 Watts PMaxx
Battery: LiIon: 21Ahr
Lighting RunTime: 12hr (at full power); power saving model 24hr.

Additional information

Weight 2 oz
Lumens 2500-2750
Battery Type Lithium
Material Aluminum Alloy
Battery Life Time 5 yrs
Brand PathLight
Dimensions 36.2" x 12.8" x 5.5"
Solar Panel Type Poly-Crystalline
Recommended mounting height 5m - 6m from ground level
Solar Panel Size 18V 50W
Recommended Distance (Light to Light) 25-35ft
LED Wattage 200W Equivalent
Diameter for the Pole 2.17" - 4.33"
LED Voltage 12V
Working Temperature -22 - 158 Degree Fahrenheit
LED Life Time 50,000 hrs
Warranty 5 Years
