8600mA 4.7W Commercial Solar Cell

8600mA 4.7W Commercial Solar Cell

$9.95 $5.95

Commercial grade solar cells. Easy to solder. Solar cells are mono-crystalline solar cells with a designed use for fabrication of solar panels.

  • Power Pmax: 4.74w
  • Voltage Voc: 0.642
  • Voltage Vpm: 0.54
  • Isc: 9.11A
  • Imp: 8.62A
  • Dimensions: 6″ x 6″ (156×156)
Availability: 833 in stock SKU: P-Maxx-6000mA Categories: ,

Questions? Just give us a call at 1-800-786-0329 9AM-5PM EST.

Live chat customer support. Most orders ship within 48 hours by FedEx. 30 day hassle free return policy. Dispatched and sold by Silicon Solar.

Share

Easy Shipping

$9.95 or free on orders over $200*

Hassle Free Returns

30 day hassle free return policy

Secure Checkout

Fast and secure checkout

Trusted Solar Partner

Family owned since 1999

Description

Commercial Solar Cells

The 0.54V  4.74W Commercial Solar Cell is ideal for home and commercial solar applications and solar panel construction of any size. Each Commercial Solar Cell features ultra-high efficiency great durability and is laser-cut to exacting specifications for precision quality control and guaranteed performance.

Item is a thin wafer Very Fragile  as a result is not returnable.

Silicon Solar provides the some of the highest grade Mono-Crystalline solar cells that are available on the consumer market. These cells are cut with laser precision accuracy that guarantees the same cell size from one to the next. Silicon Solar sells these cells in small or large quantities making them an affordable and quality choice for DIY’ers alike. An excellent choice for solar panel customization.

Photovoltaic devices use semiconducting materials to convert sunlight directly into electricity. Solar radiation which is nearly constant outside the Earth’s atmosphere varies with changing atmospheric conditions (clouds and dust) and the changing position of the Earth relative to the sun. Nevertheless almost all U.S. regions have useful solar resources that can be accessed.

Specifications:

  • Power Pmax: 4.74w
  • Voltage Voc: 0.642
  • Voltage Vpm: 0.54
  • Isc: 9.11A
  • Imp: 8.62A
  • Dimensions: 6″ x 6″ (156×156)

Customers:

Yale University (Solar Panels)
AFJ Electronic Division (Solar Cell Research)
Quiang Innovations Ltd. (Solar Cells)
Design Studio Ltd (Custom Solar Cells)
Dartmouth University (UniCells)
Sea Launch Program (Solar Cells)

Features:

  • All solar cells are tested before each shipment to ensure maximum efficiency and output.
  • Each solar cell is in new condition and not susceptible to micro-cracks a product of scrap or used cells.
  • Our skilled technical staff keeps updated on the newest solar cell technology.
  • High efficiency
  • High output
  • A proprietary anti-reflective coating provides superior color uniformity

Available Solar Cells

Don't forget the accessories you'll need

Be sure to check out our soldering iron and accessories perfect for building your solar panel project.
  • Soldering Iron – make sure you have a good quality soldering iron when soldering solar cells.
  • Flux Pen – Is essential when building a solar panel. Not all flux pens are created equal. Make sure the flux will not react with your solar cells after 1-2 years (80% of flux on market will destroy solar cell)
  • Tabbing – You’ll need 2mm and 5mm tabbing. The 2mm is for interconnecting between the solar cells, and 5mm between your “strings” of solar cells.

Plan a little before building your solar panels.

  • How many watts do you need?
  • What voltage do you need?
  • Where will the solar panel go?
  • How will you encapsulate it?

Additional information

Weight.1 lbs

1 review for 8600mA 4.7W Commercial Solar Cell

  1. 4 out of 5

    Imran Z

    cost effective and reliable solar cell.
